LM1117 3.3V TO-252-3

شناسه محصول: L1117-3.3V-TO-252-3 دسته: برچسب: ,

3,535 تومان

8 عدد در انبار


توضیحات محصول

Manufacturer: Texas Instruments
Product Category: LDO Voltage Regulators
RoHS: Details
Mounting Style: SMD/SMT
Package/Case: TO-252-3
Output Voltage: 3.3 V
Output Current: 800 mA
Number of Outputs: 1 Output
Polarity: Positive
Quiescent Current: 15 mA
Input Voltage MAX: 15 V
Input Voltage MIN: 2.6 V
Output Type: Fixed
Minimum Operating Temperature: – 40 C
Maximum Operating Temperature: + 125 C
Dropout Voltage: 1.2 V
Series: LM1117
Packaging: Cut Tape
Packaging: MouseReel
Packaging: Reel
Operating Temperature Range: – 40 C to + 125 C
Product: Linear Regulators
Type: Low Dropout Positive Regulator
Brand: Texas Instruments
Dropout Voltage – Max: 1.3 V at 100 mA, 1.35 V at 500 mA, 1.4 V at 800 mA
PSRR / Ripple Rejection – Typ: 75 dB
Voltage Regulation Accuracy: 1 %
Ib – Input Bias Current: 5 mA
Line Regulation: 1 mV
Load Regulation: 1 mV
Moisture Sensitive: Yes
Operating Supply Current: 5 mA
Product Type: LDO Voltage Regulators
Factory Pack Quantity: 2500
Subcategory: PMIC – Power Management ICs
Unit Weight: 4 g
