EVA-M8M

The GNSS SiP Module ublox EVA-M8M feature the exceptional performance of the ublox M8 positioning engine (GPS, GLONASS, BeiDou, QZSS and SBAS). The GNSS SiP Module ublox EVA-M8M series modules delivers high sensitivity and minimal acquisition times in the ultra compact EVA form factor. The GNSS SiP Module ublox EVA-M8M series is an ideal solution for cost and spacesensitive applications.

GNSS features

GNSS: BeiDou, Galileo, GLONASS, GPS / QZSS
Number of concurrent GNSS: 3
Concurrent GNSS: yes
Oscillator: Crystal

Antenna

Pin (active) for external antenn: yes
Pin (passive) for external antenna: yes

Interfaces

UART: 1
USB: 1
SPI: 1
DDC (I²C compliant): 1

Electrical data

Minimum supply [V]: 1.65
Maximum supply [V]: 3.6

Environmental data, quality & reliability

Maximum temperature [°C]: 85
Minimum temperature [°C]: -40
Size [mm]: 7 x 7 x 1.1

Features

sip (system in package)
Data logging: yes
Programmable flash memory: yes
RTC crystal: yes
Timepulse output: yes
